Size: 3″(DN80)-96″(DN2400)
Pressure: 150LB-600LB / PN16- PN100
Material: WCB, WCC, WC6, WC9, C5, C12, C12A, LCB, LCC, LC1, LC3, CF8, CF8M, CF3, CF3M, CF8C
Medium: Water, oil, gas, steam
Flange butterfly valve Wafer butterfly valve Size: 3″(DN80)-96″(DN2400) Pressure: 150LB-600LB / PN16- PN100 Material: WCB, WCC, WC6, WC9, C5, C12, C12A, LCB, LCC, LC1, LC3, CF8, CF8M, CF3, CF3M, CF8C Medium: Water, oil, gas, steam
1) Design and manufacture: API609 MSS SP-68
2) Face to face/end to end: ANSI B16.10
3) Flange dimensions: ANSI B16.5A
4) Butt welding dimensions: ANSI B16.25
5) Pressure temperature rating: ANSI B16.34
6) Inspection and test: API598
| Part Name | Material | ||||||
| Body | WCB | LCB | WC6 | CF8 | CF8M | CF3 | CF3M |
| Disc | WCB | LCB | WC6 | CF8 | CF8M | CF3 | CF3M |
| Stem | F6a | F304 | F6a | F304 | F316 | F304L | F316L |
| Seat/Seat Ring | PTFE/RPTFE/NYLON/DEVLON/PEEK or METAL | ||||||
| Packing | Graphite/PTFE | ||||||
| Gasket | SS304+Graphite/SS304+Graphite | ||||||
| Bolts/Nuts | B7/2H | L7/4 | B16/4 | B8/8 | B8M/8M | B8/8 | B8M/8M |
| Suitable Medium | W.O.G etc. | HNO3, CH3OOH etc. | |||||
| Suitable Temperature | -29~425°C | -46~340°C | -46~340°C | -196~427 °C | -196~427°C | -196~427°C | -196~427°C |
● Connection Form: Flange
● Seal Form: Force Sealed
● Work Pressure: High Pressure (1.6mpa< PN <10.0mpa)
● Material of Seal Surface: Metal Hard Sealed
● Application: Industrial Usage, Water Industrial Usage, Household Usage
● Pressure: Class150~Class1500
● Connection: Flange, Wafer, Butt-Welding
● Operator: Manual,Gear
● Structure: Three-Eccentric Sealing
● Valve Stem: Extended
● Working Temperature: Medium Temperature (120°C<T<450°C)
● Valve Body: Casting
● Size: DN40~DN2400
● Material: CI, DI, CS, SS
● Seat: Metal Seat, PTFE Seat, Rubber Seat
● HS Code: 8481804090
